We are not responsible for any damage that occurred because of the misuse or misinterpretation of our pin out diagrams. You’ll receive the file to download after the order is complete.Īs always, we recommend using a power supply tester to test your cables once you have made them. Note: For PRIME series the 18pin connector position is switched with the 10pin connectors position.
View the example diagram to get an exact (without the correct pinout of course) view of what the diagram looks like.
Save hours of work with our highly detailed and easy to follow pinout diagram! These diagrams are the same that we use when making our own custom cables for our clients so they are tested and accurate! Everything from which connectors to use and what pins require double wires is just some of the details we included for you making it easy to know which products you’ll need to make your own cables.
